1. Product application
Vibration test is to stimulate or shock a part or device to see how it will react in the real environment.Vibration testing is widely used in industrial products such as circuit boards, aircraft, ships, rockets, missiles, automobiles and household appliances.The company can provide you with the entire vibration and test scheme, and in accordance with national and international standards, such as GB, GJB, UL, JIS, DIN, ISO, BS, MIL, IEC and ASTM, to prove the quality of your products.
2. Product specifications:
Maximum sinusoidal excitation force: 1000kg. f peak
Maximum random excitation force: 1000Kg. F r.ms
Maximum shock excitation: 2000kg. f peak
Frequency range: 1 ~ 3000 Hz
Maximum displacement: 51 mm p-p
Maximum speed: 2m/s
Maximum acceleration: 100G(980m /s2)
Maximum load (sine) : F= m.5g (49m /s2) 190kg;10G (98m /s2) 90kg;20G (196 m/s2) 40kg;30 g (294 m/s2) 23 kg
First order resonance frequency: 3200 Hz + / - 5%
Payload: 300 kg
Vibration isolation frequency: 2.5hz
Moving coil diameter: 240 mm Ф
Moving coil quality: 10kg
Countertop screw hole: 16 x M10
Magnetic flux leakage: < 10gauss
Allowable eccentricity moment: 300n.m
Equipment size: 845mm x 790mm x 840mm (excluding extended table top)
Equipment weight: about 1100Kg (water-free smooth table)
SA-12K digital switching power amplifier
Output power: 12KVA
Output voltage: 100V
Output current: 100A
Amplifier efficiency: greater than 90%
Switching frequency: 116KHz
SNR: greater than or equal to 65dB
Noise: 70 db or less
Amplifier size: 880mm x 590mm x 1720mm
Servo protection system
Function: temperature, wind pressure, over displacement, over voltage, over current, under voltage input, external fault, control power supply, logic fault, input lack equal
Digital vibration controller vcsusb-2
Hardware configuration: 2 input channels and 1 output channel
Sine, random, typical shock
Control computer original computer with 17 "LCD, keyboard/photoelectric mouse
Software in English/Chinese operation, can be used for time domain and frequency domain analysis, signal source, sinusoidal sweep frequency analysis.Can automatically generate WORD test report, signal and data display, storage, setting test parameters and analysis functions.
Operating system Windows7/10
Acceleration sensor LAB frequency range: 1-12000hz
Sensitivity: 50PC/g
Temperature range: - 40-160 ℃
VT660 vertical extension table top
Material: aluminum alloy, hard anodic surface treatment
Or: 600 mm * 600 mm
Fixed hole position: M8 stainless steel screw sleeve, durable and wear-resistant
Frequency of use: 2000Hz
Weight: 35 kg
H0606 horizontal oil film slide table
Material: aluminum alloy, hard anodic surface treatment
Or: 600 mm * 600 mm
Fixed hole position: M8 stainless steel screw sleeve, durable and wear-resistant
Frequency of use: 2000Hz
Weight: 38KG (without connector)
Bl-1000 cooling fan (including silencer)
Fan power: 4KW
Traffic: 22 m3 / Min
Electrical requirements:
Power source: AC3 phase 380V/50Hz, 25kva
Compressed air: 0.6mpa
Grounding resistance: 4 or less Ω
