1、 Scope of application:
This machine is used to test the fatigue resistance of the stationery box surface after repeated 90 degree opening and closing. After a certain number of tests, observe whether there is any fracture. The equipment adopts a touch screen programming control system, and the power is transmitted by servo motors. The fixture rotates and is fixed quickly, which is fast and easy to use. This device complies with standard QB/T1587-2006 6.2
2、 Technical parameters:
1. Test speed: 60 times/minute
2. Display: Touch screen controller, automatically shuts down after completing the set number of times
3. Folding angle: 90 degrees
4. Dimensions (length x width x height): 650mm x 500mm x 500mm
5. Weight: 45kg
6. Power supply: AC220V 50HZ
